TECHNICAL SPECIFICATIONS
HARDWARE INFORMATION |
| RW5800ND-A | RW5800ND-B |
Processor主芯片 | Qualcomm AR9342（560 MHz）Network Processor | Qualcomm AR9344（560 MHz）Network Processor |
System Memory内存 | 64MB（max 128MB optional）DDR SDRAM |
NOR Flash Flash | 8MB（max 16MB optional） |
Power Amplifier功放 | RFMD5542 | SKY5004L |
Antenna天线接口 | U.FL |
PCIe Slot | Nothing | 1 x 9.2 mm Mini PCIe slot（USB） |
Ethernet端口 | 1 X 10/100 Base-T Ethernet Port（with Auto MDI / MDIX） | 2 X 10/100 Base-T Ethernet Port（with Auto MDI / MDIX） |
Flat Cable排线 | 1 x10pin hole（孔） |
Serial Port | 1 x 4pin header（TTL） |
Reset | Push Button Reset按钮复位 |
Remote hardware reset（Optional）远程硬件复位(可选) |
Watch Dog Timer | Yes |
PoE | Passive PoE （range 9V-28V DC） |
DC Jack Input (optional) | Range 9V-28V DC |
Power Consumption | 6W (Host Board only) |
RoHS Compliance | Yes（Optional）(可选) |
Humidity | Operating: 5% to 95%（non-condensing）Storage: Max.90% （non-condensing） |
Temperature Range | Operating: -20ºC to 70ºC Storage: -40ºC to 90ºC |
Dimensions | 115 x 78 x 16（mm） |
Weight | 110g |
RF MODULE（AR9342） |
频率范围 | 5.1～5.8GHz |
RF功率输出 | 500mW |
接收灵敏度 | 802.11n_HT40 | 802.11n_HT20 | 802.11a | 802.11n_HT40 |
-88dBm @MCS0 | -90dBm @MCS0 | -90dBm@6-24Mbps | -88dBm @MCS0 |
-71dBm @MCS7 | -72dBm @MCS7 | -75dBm @54 Mbps | -71dBm @MCS7 |
发射功率 | 802.11n_HT40 | 802.11n_HT20 | 802.11a | 802.11n_HT40 |
28dBm @MCS0 | 28Bm @MCS0 | 28dBm @6-24Mbps | 28dBm @MCS0 |
19dBm @MCS7 | 20dBm @MCS7 | 26dBm @54 Mbps | 19dBm @MCS7 |
SOFTWARE INFORMATION |
Firmware Support | Redwave，OpenWRT，DD-WRT |
① The input power can come from an Ethernet port and it is fed to the other Ethernet port so that it can in turn drive another Passive PoE device.
② Serial Converter available to change the TTL signals on board to RS232 signals for debugging Configurations are subject to change without notice.
③ Please contact Redwave sales representatives for other available configurations.
