Features
● Atheros 74Kc MIPS Processor with 64KB I-Cache and 32KB D-Cache ，operating at
up to 535MHz
●
2.4GHz 300Mbps（500mW 2T2R）
● 2 Ethenet ports
● Integrated passive Power-over-Ethernet
● Integrated with PoE cascade arrangement
● PA：RTC6649&PA：SKY2576
TECHNICAL SPECIFICATIONS
| HARDWARE INFORMATION |
Processor | AR9341（550 MHz）+ PA：RTC6649/SKY2576 |
General Usage | CPE |
System Memory | 64MB（max 64MB optional）DDR SDRAM |
NOR Flash | 8MB（max 16MB optional） |
PCIe Slot | 1 x 9.2 mm Mini PCIe slot |
Ethernet | 2 X 10/100 Base-T Ethernet Port（with Auto MDI / MDIX） |
USB | 1 x USB 2.0 D+ D Connector（焊盘） |
Serial Port | 1 x 4pin header（TTL） |
Reset | Push Button Reset |
Remote hardware reset（Optional） |
Watch Dog Timer | Yes |
PoE | Passive PoE （range 9V-28V DC） |
DC Jack Input (optional) | Range 5V-28V DC |
Power Consumption | 3W (Host Board only) |
RoHS Compliance | Yes |
Humidity | Operating: 5% to 95%（non-condensing）Storage: Max.90% （non-condensing） |
Temperature Range | Operating: -20ºC to 70ºC Storage: -40ºC to 90ºC |
Dimensions | 115 x 70 x 16（mm） |
Weight | 100g |
SOFTWARE INFORMATION |
Firmware Support | Redwave，OpenWRT，DD-WRT |
① The input power can come from an Ethernet port and it is fed to the other Ethernet port so that it can in turn drive another Passive PoE device.
② Serial Converter available to change the TTL signals on board to RS232 signals for debugging Configurations are subject to change without notice.
③ Please contact Redwave sales representatives for other available configurations.
